ATLAS COPCO PAS-300MF-390 Centrifugal Pump

Product variants

Details

The PAS pump system consists of a centrifugal pump and a SuperDuo separator, which enables air to be separated from the liquid and be sucked by a vacuum pump – making automatic priming possible. Even with suction heights of several meters, the machine rapidly evacuates the air from the suction pipe and starts to pump. Additionally, thanks to the semi-open impeller, the PAS range is also suitable for pumping liquids with solids in suspension.

Both Atlas Copco and Varisco have decades of experience in designing and producing pumps. We have put those years of expertise into providing a solutions portfolio that works across multiple applications. The PAS MF (medium flow) range is packed with features that not only meet, but exceed the needs of the market. We are focused on an efficient, extremely versatile pump that is suitable for many industries, including construction, general dewatering and emergency applications, such as flood clean up.

Features

Pump High efficiency: 60% (B.E.P.)

Rapid ""dry"" priming: Up to a height of 8.5 m (27.5 ft)

High resistance: To abrasive liquids and turbid sandy waters

Semi-open impeller: Solids handling up to 76 mm (3"")

Easy maintenance: Hinged cover for direct access to the impeller

Rotary vane vacuum pump: Lubricated with oil recovery system and coalescing filters: no contamination of the environment

Wear plates: Cast iron or stainless steel (F10) wear plate, that is easily replaceable

Atlas Copco PAS-300MF-390 Centrifugal Pump

Overview

The PAS 300MF 390 centrifugal pump has a maximum capacity of 1130m³/h, a suction/ discharge of DN300(12″), a maximum head of 29.5m, a maximum solids of 76 and a water cooled Perkins engine.

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Read our complete warranty terms & conditions here.

All our online payment methods are secured.

PAS-300MF-390-Centrifugal-Pump

GO Industrial Dry Prime PAS Pumps

Specifications

Maximum Capacity: 1130m3/hSuction/ Discharge: DN300 (12"")Maximum Head: 29.5mMaximum Solids: 76Engine: Air Cooled PerkinsPower: 92.1kW

Priming System	PAS-300MF-390
Vacuum pump	V04
Vacuum pump type	Rotary Vane
Nominal air capacity	75 m³/h (44.1 cfm)
Max vacuum	0,9
Bar Separator type	Superduo
Separator material	EN-GJL-200 cast iron

Pump	PAS-300MF-390
Qmax	1.130 m³/h - 18.830 l/min (5,000 USgpm)
Hmax	29,5 m (97 ft)
Q max eff.	725 m³/h - 12.080 l/min (3,200 USgpm)
Eff. max	60 %
Suction port	Flanged - DIN 300
Delivery port	Flanged - DIN 300
Impeller type	Semi-Open, 2 vane
Solids handling	76 mm (3"")

Features

Pump High efficiency: 60% (B.E.P.)
Rapid ""dry"" priming: Up to a height of 8.5 m (27.5 ft)
High resistance: To abrasive liquids and turbid sandy waters
Semi-open impeller: Solids handling up to 76 mm (3"")
Easy maintenance: Hinged cover for direct access to the impeller
Rotary vane vacuum pump: Lubricated with oil recovery system and coalescing filters: no contamination of the environment
Wear plates: Cast iron or stainless steel (F10) wear plate, that is easily replaceable
