GO 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open Solenoid Valve
SKU: ES58-2-1.5GO 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open Solenoid Valve
Other payment options
GO 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open Solenoid Valve
GO 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open Solenoid Valve
Overview
A three way normally open (power to close) direct acting solenoid valve with a 304 Stainless Steel machined body and stainless steel operator. Suitable for low head and zero head applications with a Viton (FKM) seat. Liquids to 50 centistoke viscosity. Standard coil is weatherproof to IP65 and has LED illuminated plug.
Specifications
304 S.S 3 way 2 position normally open zero differential solenoid valve.G1/4", 1.5mm orifice, 304 SS operator, copper shading ring, FKM seat.0-16 BAR pressure range, media temp -10°C to 100°C.Coil Class H insulation, 11 Volt Amps, IP65 protection.
| Model | Port Size | Orifice ø | CV | Pressure (BAR) | Media Temp | Weight | Coil |
|---|---|---|---|---|---|---|---|
| ES58-2-1.5-*V | ¼” BSP | 1.5 mm | 0.075 | 0 to 16 | -10°C to 100°C | 0.8 kg | SC-N12 15 Watts 11 VA |
