GO Solenoid Valve 1/4
Dimensions - GO Solenoid Valve 1/4
  • GO Solenoid Valve 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open
  • Dimensions - GO Solenoid Valve 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open
1 3

GO 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open Solenoid Valve

SKU: ES58-2-1.5

GO 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open Solenoid Valve

$83.00 AUD
$83.00 AUD
Inclusive of GST. Shipping calculated at checkout.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.

Other payment options

GO 1/4" ES58 304 Stainless 3 Way Direct Acting Normally Open Solenoid Valve

Overview

A three way normally open (power to close) direct acting solenoid valve with a 304 Stainless Steel machined body and stainless steel operator. Suitable for low head and zero head applications with a Viton (FKM) seat. Liquids to 50 centistoke viscosity. Standard coil is weatherproof to IP65 and has LED illuminated plug.

Details

Typical applications include use as a pilot valve, tank drain, iodine dosing for dairies, chemicals and other general industry. Two body female ports with a male threaded operator port.

Specifications

304 S.S 3 way 2 position normally open zero differential solenoid valve.G1/4", 1.5mm orifice, 304 SS operator, copper shading ring, FKM seat.0-16 BAR pressure range, media temp -10°C to 100°C.Coil Class H insulation, 11 Volt Amps, IP65 protection.

  • Size 1/4" BSP only
  • Function 3 way normally Open (power to close)
  • Valve Operation Direct Acting
  • Body 304 Stainless Steel
  • Seat FKM
  • Pressure Range 0 to 16 BAR
  • Media Petrochemical, Air, Fluid
Model Port Size Orifice ø CV Pressure (BAR) Media Temp Weight Coil
ES58-2-1.5-*V ¼” BSP 1.5 mm 0.075 0 to 16 -10°C to 100°C 0.8 kg SC-N12
15 Watts
11 VA
