GO CI Body 316 SS Disc EPDM Liner BFDE Butterfly Valves Actuated Electric

SKU: BFD50-E

GO CI Body 316 SS Disc EPDM Liner BFDE Butterfly Valves Actuated Electric

$600.00 AUD
$600.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
Size
Seat

Other payment options

View full details
GO CI Body 316 SS Disc EPDM Liner BFDE Butterfly Valves Actuated Electric - GO Industrial - BFD50 - E

GO CI Body 316 SS Disc EPDM Liner BFDE Butterfly Valves Actuated Electric

From $600.00 AUD
From $600.00 AUD
Save $0
Sold out

Details

Common applications include water trucks, irrigation, cement hoppers, irrigation and other industrial applications. If sizes above 600mm are required please contact us.

GO CI Body 316 SS Disc EPDM Liner BFDE Butterfly Valves Actuated Electric

Overview

The BFD series has a cast iron body, 316 S.S disc, EPDM seat and an electric actuator making it suited to a wide range of industrial applications. These wafer butterfly valves will fit all standard flanges and are operated by a high quality IP67 electric actuator (available in all voltages). The unique bonded cartridge design of the butterfly valve gives it a longer life span, allows vacuum to be run through it and enables the seat to be replaceable if ever the need should arise.

    Shipping & Returns

    Our network of warehouses Australia-wide enables us to
    deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

    All returns must be pre-approved to ensure replacement and / or refund.

    Shipping & Returns

    Our network of warehouses Australia-wide enables us to
    deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

    All returns must be pre-approved to ensure replacement and / or refund.

    Warranty

    Read our complete warranty terms & conditions here.

    Warranty

    Read our complete warranty terms & conditions here.

    Secure Payment

    All our online payment methods are secured.

    Secure Payment

    All our online payment methods are secured.

    Specifications

  • Size 50mm to 600mm
  • Body FBE coated Cast Iron
  • Seat EPDM
  • Disc 316 Stainless Steel
  • Pressure 16 BAR
  • Actuation Electric
    • Model Size (mm) Actuator Media Pressure Media Temperature Actuator Pressure
    BFD50-E*-E 50 0M-1 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD65-E*-E 65 0M-1 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD80-E*-E 80 0M-1 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD100-E*-E 100 0M-A Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD125-E*-E 125 0M-A Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD150-E*-E 150 0M-2 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD200-E*-E 200 0M-3 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD250-E*-E 250 0M-4 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD300-E*-E 300 0M-5 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
    BFD350-E*-E 350 0M-6 Vacuum to 10 BAR -20°C to 120°C 6 to 8 BAR
    BFD400-E*-E 400 0M-7 Vacuum to 10 BAR -20°C to 120°C 6 to 8 BAR
    BFD450-E*-E 450 0M-8 Vacuum to 10 BAR -20°C to 120°C 6 to 8 BAR
    BFD500-E*-E 500 0M-9 Vacuum to 10 BAR -20°C to 120°C 6 to 8 BAR
    BFD600-E*-E 600 0M-11 Vacuum to 10 BAR -20°C to 120°C 6 to 8 BAR
