TRADEQUIP Engine Crane 3T Rated

SKU: 1193

TRADEQUIP Engine Crane 3T Rated

$2,077.00 AUD
$2,077.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.

Other payment options

View full details
TRADEQUIP Engine Crane 3T Rated - GO Industrial - 1193

TRADEQUIP Engine Crane 3T Rated

$2,077.00 AUD
$2,077.00 AUD
Save $0
Sold out

Details

The jib extends to the desired lifting capacity of 1000kg, 2000kg or 3000kg secured by a single locking pin. Mounted on heavy duty castor wheels for excellent manoeuvrability around the workshop. The lifting range is 0-2500mm so any large engine can be lifted clear out of the engine bay with little effort. With great stability of its wide legs, this crane can also be used to lift machines or other heavy items, making for an excellent piece of equipment for the workshop or warehouse.

Intended Use

For regular professional use, to raise and/or lower diesel engines and transmissions during service or repair work.

Features

  • Industrial grade engine crane
  • Heavy duty hydraulic pump
  • Adjustable boom in four positions for lifting
  • Robust steel fabricated legs with structural supports
  • Large castor wheels for easy mobility

    • TradeQuip Engine Crane 3T Rated

    Overview

    This heavy duty TradeQuip "Made for the Trade" engine crane has a long stroke lifting ram, a single action pump with a maximum load capacity of 3,000kg. Very simple to use manual hydraulic operation.

            Shipping & Returns

            Our network of warehouses Australia-wide enables us to
            deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

            All returns must be pre-approved to ensure replacement and / or refund.

            Shipping & Returns

            Our network of warehouses Australia-wide enables us to
            deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

            All returns must be pre-approved to ensure replacement and / or refund.

            Warranty

            Read our complete warranty terms & conditions here.

            Warranty

            Read our complete warranty terms & conditions here.

            Secure Payment

            All our online payment methods are secured.

            Secure Payment

            All our online payment methods are secured.

            • TradeQuip 1193 Manual

            Specifications

          • Safe Working Capacity: 3,000kg
          • Folded Height: 1625mm
          • Maximum Lifting Height @ 3000kg: 2200mm
          • Maximum Lifting Height @ 1000kg: 2500mm
          • Jib Length Fully Retracted @ 3000kg: 1370mm
          • Jib Length Fully Extended @ 1000kg: 1980mm
          • Overall Length Fully Extended: 2385mm
          • Overall Length Fully Retracted: 1470mm
          • Overall Width Fully Extended: 875mm
          • Overall Width Fully Retracted: 785mm
          • Leg Height 195mm

              • Features

            • Industrial grade engine crane
            • Heavy duty hydraulic pump
            • Adjustable boom in four positions for lifting
            • Robust steel fabricated legs with structural supports
            • Large castor wheels for easy mobility
