GO B55 Brass Petrochemical Zero Differential Normally Closed Solenoid Valves

SKU: B55-3-15-7V

GO B55 Brass Petrochemical Zero Differential Normally Closed Solenoid Valves

$209.00 AUD
$209.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
Size
Orifice

Other payment options

View full details
GO B55 Brass Petrochemical Zero Differential Normally Closed Solenoid Valves - GO Industrial - B55 - 3 - 15 - 7V

GO B55 Brass Petrochemical Zero Differential Normally Closed Solenoid Valves

From $209.00 AUD
From $209.00 AUD
Save $0
Sold out

Details

Typical Applications include: Petrochemical, diesel farms, vacuum packaging, tank drain or low pressure service & general industry.

GO B55 Brass Petrochemical Zero Differential Normally Closed Solenoid Valves

Overview

A high flow valve with brass forged body and stainless steel operator. Suitable for low head and zero head applications. available in various seat materials including Viton (standard), Silicone, Neoprene, EPDM & Nitrile (contact us for any seals other than standard). Liquids to 40cst viscosity. Standard coil is weatherproof to IP65 and has LED illuminated plug.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Warranty

Read our complete warranty terms & conditions here.

Warranty

Read our complete warranty terms & conditions here.

Secure Payment

All our online payment methods are secured.

Secure Payment

All our online payment methods are secured.

Specifications

Brass 2 way 2 position normally closed zero differential solenoid valve.G3/8", 15mm orifice, 304 SS operator, copper shading ring, FKM seat.0-10 BAR pressure range, vacuum 27"Hg, media temp -10°C to 100°C.Coil Class H insulation, 17.5 Watts, IP65 protection.

  • Size 3/8" to 2" BSP
  • Function Normally Closed (power to open)
  • Valve Operation Coupled Diaphragm
  • Body Forged Brass
  • Seat FKM
  • Pressure Range 0 to 10 BAR
  • Media Petrochemical
    • Model Port Size BSP Orifice ømm CV Pressure (BAR) Media Temperature Repair Kit Coil Specifications
    B55-3-15-*V 3/8 15 4.5 0 to 10 -10°C to 100°C RK-B55-4-V SC-C2
    24.4 Volt Amps
    18 Watts
    Class F Insulation
    100% ED
    B55-4-15-*V ½ 15 4.5 0 to 10 -10°C to 100°C RK-B55-4-V
    B55-5-20-*V ¾ 20 9.3 0 to 10 -10°C to 100°C RK-B55-5-V
    B55-6-25-*V 1 25 13.2 0 to 10 -10°C to 100°C RK-B55-6-V
    B55-7-35-*V 1 ¼ 35 26 0 to 10 -10°C to 100°C RK-B55-8-V
    B55-8-35-*V 1 ½ 35 26 0 to 10 -10°C to 100°C RK-B55-8-V
    B55-9-50-*V 2 50 48 0 to 7 -10°C to 100°C RK-B55-9-V
