Features
Graco Merkur 48:1 Cart-Mount Airless Sprayer
Overview
Graco Merkur X48 Airless Sprayers for protective coatings are ideal for touch-ups or other smaller projects. The sprayer's light weight and portability make it a great mobile auxiliary system to finish jobs in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.
- High-Pressure Airless Sprayers for Protective Coatings
- Portable, lightweight (just 45kg) sprayer for a wide range of protective coatings projects and easy maneuverability
- Compact size allows for spraying in the smallest of areas
- Offers a unique combination of power and portability.
- Capable of spraying medium to high solids materials at pressures up to 4800 psi (330 bar), the Merkur series handles a wide range of hot potted protective coatings applications.
- Ideal for one-gun applications using up to 0.025 in tip
- Affordable – get high quality results with minimal investment
- Flexible – ideal for a wide range of applications, including marine, rail and steel fabrication
- Compact – fits into tight areas
- Sprays medium to higher solids coatings – up to 4800 psi (331 bar)
- Ideal for applications such as steel fabrication, marine, rail, industrial and structural steel
- Easy to use, easy to clean
- Stainless steel option allows for waterborne coatings
- The Merkur Airless Sprayer for protective coatings is ideal for touch-ups or other smaller projects. Its light weight and portability make it a great mobile auxiliary system to finish up a job in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.
Specifications
| COMPATIBLE MATERIAL | Protective Coating |
|---|---|
| FLUID INLET SIZE (IN) | 1-1/4 |
| FLUID INLET SIZE (MM) | 31.75 |
| FLUID INLET THREAD TYPE | NPT |
| FLUID OUTLET SIZE (IN) | 3/8 |
| FLUID OUTLET SIZE (MM) | 9.525 |
| FLUID OUTLET THREAD TYPE | NPT |
| HOSE INLET DIAMETER (CM) | 0.9525 |
| HOSE INLET DIAMETER (IN) | 3/8 |
| HOSE INLET DIAMETER (MM) | 9.525 |
| INLET PAINT STRAINER | 8 Mesh, 16 Mesh |
| MAXIMUM SOUND PRESSURE LEVEL (DB(A)) | 68.9 |
| MAXIMUM TIP SIZE (IN) | 0.025 |
| MAXIMUM WORKING PRESSURE (PSI) | 4800 |
| MAXIMUM WORKING PRESSURE (KPA) | 33100 |
| POWER SOURCE | Pneumatic |
| MAXIMUM WORKING PRESSURE (MPA) | 33.1 |
| PRESSURE CONTROL TYPE | Air Regulator |
| MODEL | Merkur |
| MAXIMUM WORKING PRESSURE (BAR) | 331 |
| WEIGHT (KG) | 45 |
| WEIGHT (LB) | 99 |
| SERIES | X48/X72 |
| PUMP TYPE | Displacement Pump, Pneumatic Piston Pump |
| TYPE | Airless Sprayer |
| MOTOR TYPE | Pneumatic Motor |
| PUMP SLEEVE MATERIAL | Stainless Steel |
| PUMP ROD TYPE | Carbon Steel |
| NUMBER OF GUNS | 0 |
| MOUNT TYPE | Cart Mount |
| PUMP PRESSURE RATIO | 48:1 |
| LOWER CONFIGURATION | Carbon Steel;1-1/4 in. Inlet;Drain Valve |
| PACKAGE OPTIONS | Bare (No Hose/Gun) |
| MAXIMUM AIR CONSUMPTION (SCFM) | 60 |
| FLUID OUTLET THREAD GENDER | Male |
| VOLUME PER CYCLE (CM³) | 75 |
