We’re here to help
Equipment specialists ready to go above and beyond. Expert advice, 1:1 support and care that you’d expect from a premium brand.
Message a Specialist sales@goind.com.auEnquire For Price
Features:
- High-Pressure Airless Sprayers for Protective Coatings
- Portable, lightweight (just 45kg) sprayer for a wide range of protective coatings projects and easy maneuverability
- Compact size allows for spraying in the smallest of areas
- Offers a unique combination of power and portability.
- Capable of spraying medium to high solids materials at pressures up to 4800 psi (330 bar), the Merkur series handles a wide range of hot potted protective coatings applications.
- Ideal for one-gun applications using up to 0.025 in tip
- Affordable – get high quality results with minimal investment
- Flexible – ideal for a wide range of applications, including marine, rail and steel fabrication
Product Range
- 16V175 - Bare Unit
- 16U920 - Complete Package
Standard Inclusions - 16U920
- XTR gun with 519 tip
- 3/8 in x 25 ft (7.6 m) hose, 6 ft (1.8 m) whip
- Compact – fits into tight areas
- Sprays medium to higher solids coatings – up to 4800 psi (331 bar)
- Ideal for applications such as steel fabrication, marine, rail, industrial and structural steel
- Easy to use, easy to clean
- Stainless steel option allows for waterborne coatings
- The Merkur Airless Sprayer for protective coatings is ideal for touch-ups or other smaller projects. Its light weight and portability make it a great mobile auxiliary system to finish up a job in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.
Technical Specifications
COMPATIBLE MATERIAL | Protective Coating |
---|---|
FLUID INLET SIZE (IN) | 1-1/4 |
FLUID INLET SIZE (MM) | 31.75 |
FLUID INLET THREAD TYPE | NPT |
FLUID OUTLET SIZE (IN) | 3/8 |
FLUID OUTLET SIZE (MM) | 9.525 |
FLUID OUTLET THREAD TYPE | NPT |
HOSE INLET DIAMETER (CM) | 0.9525 |
HOSE INLET DIAMETER (IN) | 3/8 |
HOSE INLET DIAMETER (MM) | 9.525 |
INLET PAINT STRAINER | 8 Mesh, 16 Mesh |
MAXIMUM SOUND PRESSURE LEVEL (DB(A)) | 68.9 |
MAXIMUM TIP SIZE (IN) | 0.025 |
MAXIMUM WORKING PRESSURE (PSI) | 4800 |
MAXIMUM WORKING PRESSURE (KPA) | 33100 |
POWER SOURCE | Pneumatic |
MAXIMUM WORKING PRESSURE (MPA) | 33.1 |
PRESSURE CONTROL TYPE | Air Regulator |
MODEL | Merkur |
MAXIMUM WORKING PRESSURE (BAR) | 331 |
WEIGHT (KG) | 45 |
WEIGHT (LB) | 99 |
SERIES | X48/X72 |
PUMP TYPE | Displacement Pump, Pneumatic Piston Pump |
TYPE | Airless Sprayer |
MOTOR TYPE | Pneumatic Motor |
PUMP SLEEVE MATERIAL | Stainless Steel |
PUMP ROD TYPE | Carbon Steel |
NUMBER OF GUNS | 0 |
MOUNT TYPE | Cart Mount |
PUMP PRESSURE RATIO | 48:1 |
LOWER CONFIGURATION | Carbon Steel;1-1/4 in. Inlet;Drain Valve |
PACKAGE OPTIONS | Bare (No Hose/Gun) |
MAXIMUM AIR CONSUMPTION (SCFM) | 60 |
FLUID OUTLET THREAD GENDER | Male |
VOLUME PER CYCLE (CM³) | 75 |
Graco Merkur 48:1 Cart-Mount Airless Sprayer
SKU: 16V175Graco Merkur 48:1 Cart-Mount Airless Sprayer
Other payment options
The Basics
Graco Merkur X48 Airless Sprayers for protective coatings are ideal for touch-ups or other smaller projects. The sprayer's light weight and portability make it a great mobile auxiliary system to finish jobs in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.
Features:
- High-Pressure Airless Sprayers for Protective Coatings
- Portable, lightweight (just 45kg) sprayer for a wide range of protective coatings projects and easy maneuverability
- Compact size allows for spraying in the smallest of areas
- Offers a unique combination of power and portability.
- Capable of spraying medium to high solids materials at pressures up to 4800 psi (330 bar), the Merkur series handles a wide range of hot potted protective coatings applications.
- Ideal for one-gun applications using up to 0.025 in tip
- Affordable – get high quality results with minimal investment
- Flexible – ideal for a wide range of applications, including marine, rail and steel fabrication
Product Range
- 16V175 - Bare Unit
- 16U920 - Complete Package
Standard Inclusions - 16U920
- XTR gun with 519 tip
- 3/8 in x 25 ft (7.6 m) hose, 6 ft (1.8 m) whip
- Compact – fits into tight areas
- Sprays medium to higher solids coatings – up to 4800 psi (331 bar)
- Ideal for applications such as steel fabrication, marine, rail, industrial and structural steel
- Easy to use, easy to clean
- Stainless steel option allows for waterborne coatings
- The Merkur Airless Sprayer for protective coatings is ideal for touch-ups or other smaller projects. Its light weight and portability make it a great mobile auxiliary system to finish up a job in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.
Technical Specifications
COMPATIBLE MATERIAL | Protective Coating |
---|---|
FLUID INLET SIZE (IN) | 1-1/4 |
FLUID INLET SIZE (MM) | 31.75 |
FLUID INLET THREAD TYPE | NPT |
FLUID OUTLET SIZE (IN) | 3/8 |
FLUID OUTLET SIZE (MM) | 9.525 |
FLUID OUTLET THREAD TYPE | NPT |
HOSE INLET DIAMETER (CM) | 0.9525 |
HOSE INLET DIAMETER (IN) | 3/8 |
HOSE INLET DIAMETER (MM) | 9.525 |
INLET PAINT STRAINER | 8 Mesh, 16 Mesh |
MAXIMUM SOUND PRESSURE LEVEL (DB(A)) | 68.9 |
MAXIMUM TIP SIZE (IN) | 0.025 |
MAXIMUM WORKING PRESSURE (PSI) | 4800 |
MAXIMUM WORKING PRESSURE (KPA) | 33100 |
POWER SOURCE | Pneumatic |
MAXIMUM WORKING PRESSURE (MPA) | 33.1 |
PRESSURE CONTROL TYPE | Air Regulator |
MODEL | Merkur |
MAXIMUM WORKING PRESSURE (BAR) | 331 |
WEIGHT (KG) | 45 |
WEIGHT (LB) | 99 |
SERIES | X48/X72 |
PUMP TYPE | Displacement Pump, Pneumatic Piston Pump |
TYPE | Airless Sprayer |
MOTOR TYPE | Pneumatic Motor |
PUMP SLEEVE MATERIAL | Stainless Steel |
PUMP ROD TYPE | Carbon Steel |
NUMBER OF GUNS | 0 |
MOUNT TYPE | Cart Mount |
PUMP PRESSURE RATIO | 48:1 |
LOWER CONFIGURATION | Carbon Steel;1-1/4 in. Inlet;Drain Valve |
PACKAGE OPTIONS | Bare (No Hose/Gun) |
MAXIMUM AIR CONSUMPTION (SCFM) | 60 |
FLUID OUTLET THREAD GENDER | Male |
VOLUME PER CYCLE (CM³) | 75 |
