ATLAS COPCO U110 PACE Utility Series 8 Air Compressor

SKU U110PACE
Afterpay Zip PayPal LeaseGO
Tax included. Shipping calculated at checkout.
Contact for pricing
No stock main warehouse, contact for lead time

Same-day dispatch

In-stock orders by 2pm AEST

Australia-wide delivery

Direct to your job from Brisbane

Authorised service

In-house warranty + repairs

Trade pricing for all

No trade-only accounts

Product details

Built for the work it does.

The U110 PACE compressor is a new addition to the 8 Series Utility range. This compressor features an innovative controller allowing for multiple pressure configurations between 5-10.5 bar.

Thanks to its PACE (Pressure Adjust through Cognitive Electronics) system, operators are able to choose from the widest operating pressure range currently available for a truck-mounted air compressor. With the PACE electronic regulation system, operators use a simple-to-use digital controller to adjust the pressure with pinpoint accuracy depending on their application need. This means that with the U190 PACE compressor any theoretical combinations from 5 up to 10.5 bar is achievable.

The 8 Series Utility range is light weight, copact package. This range may not have any wheels, but all the integrated features mean we are proud to call this a mobile, easy to move compressor.

All 8 Series compressors are under 750 kg and service can always be completed under one hour. The Utility range offers models with our revolutionary PACE system. PACE enables you to control the pressure and regulate the flow – giving you even more versatility to handle the toughest applications. All models come with a corrosion free C3 rated canopy.

    Features

    Features

  • Best in class fuel efficiency
  • A footprint at least 10% smaller than comparable models
  • Anti-air lock starting systems
  • High humidity C3 corrosion protection
  • 1000 hours service interval
  • Integrated lifting slots and top-hook
  • Enough fuel autonomy to run a full shift
  • Specifications

    Performance

    Normal effective working pressure

    bar(g)

    5-10,5

    Normal Effective working pressure

    psig

    70-150

    Actual free air delivery

    cfm

    45-100

    Max. ambient temperature at sea level degrees celsius 50
    Min. starting temperature/ cold start kit degrees celsius -10/-20

    Engine

    Make

    Kubota

    Type

    D902

    Number of cylinders

    3

    Output at rated speed

    18,5 kW

    Engine Speed (nominal) 3600 rpm
    Engine speed (unloaded) 2000 rpm
    Capacity engine oil system 3L
    Capacity compressor oil 5L
    Fuel Tank 30L
    Cooling system 5L


    Dimensions

    Length (including - fixed tow bar) 1580mm
    Width 740mm
    Height 850mm
    Weight 498kgs
