Maintenance Fluids.

Keep your line marking equipment in top shape with our professional maintenance fluids. This collection has everything you need to protect your investment, from high-performance hydraulic oil and Engine Oil to specialised products like pump armour storage solution and Throat Seal Liquid Lubricator. Using these essential fluids will extend the life of your machinery, boost efficiency, and prevent costly downtime. Ensure your gear is always ready for the next job with these professional-grade solutions.

FAQs

Common questions answered.

Five of the questions we hear most often on carpark and street linemarking gear. Full knowledge base on our FAQ page.

  • Why use genuine Graco hydraulic fluid?

    The LineLazer V hydraulic pump is engineered around the viscosity, additive package and operating temperature range of Graco-spec hydraulic fluid (207428, 3.8 L bottle). Running non-Graco-spec fluid changes pump performance, accelerates seal wear, and voids the Graco warranty on the hydraulic pump assembly. Replace at the service interval specified in the Graco operator manual; top-up between intervals if level drops.

  • Fusion ProConnect or Fusion AP grease: which do I need?

    Match the grease to the gun. Fusion ProConnect (Fusion PC) takes the 4 oz tube (118665). Fusion Air-Purge (Fusion AP) takes the 3 oz tube (117792). Both are plural-component-safe, meaning the lubricant will not contaminate the resin / catalyst streams in the gun mixing chamber. Standard general-purpose grease is not suitable; it can transfer to the mix chamber and cause catastrophic gun failure on the LineLazer V 200MMA cold applied plastic units.

  • When do I need food-grade lubricant?

    Whenever the line marking work is inside a food-processing facility, dairy, meatworks, beverage plant or similar environment with food-grade compliance requirements (NSF-H1 or equivalent). The Graco Food Grade Lubricant Grease 3 oz (117773) is NSF-certified for these environments. Confirm the facility compliance requirement before specifying, using a non-food-grade lubricant in a food-processing facility can fail an audit and require a full unit decontamination.

  • Do I need Pump Armour?

    Yes. Pump Armour 1 gallon (Graco 245133) is the standard end-of-shift flush fluid that protects the pump and packings from drying paint between shifts. Without it, dried paint residue accelerates packing wear and is the single biggest cause of full-pump-rebuild service jobs. Currently a catalog gap on this collection, talk to GO Industrial if you need Pump Armour sourced through Graco AU. In the meantime, the standard end-of-shift workflow is a clean-water flush on waterborne paint or appropriate solvent on solvent paint, followed by a Pump Armour fill on the pump for storage.

  • How often do I service the gun grease?

    Service per the Graco operator manual interval for your specific gun. As a working rule, inspect the gun grease at every shift change on production work, top up at every service interval, and carry one spare grease tube on the truck for any council shift longer than three days. Running a Fusion gun without adequate grease accelerates trigger and needle wear and can cause material drag through the mixing chamber.

Full guide

Choosing the Right Maintenance Fluid

Genuine Graco service fluids extend pump rebuild interval, keep the Fusion ProConnect mixing chamber clean, and prevent the catastrophic gun and pump failures that come from running aftermarket lubricants on plural-component or hydraulic systems. Pick by the unit class and the service interval.

Hydraulic fluid for LineLazer V hydraulic pumps. The Graco Hydraulic Fluid 3.8 L Bottle (207428) is the genuine Graco-spec hydraulic fluid for LineLazer V hydraulic pump systems. Top-up between scheduled service intervals; full changeout at the interval specified in the Graco operator manual for your unit. Running non-Graco-spec hydraulic fluid voids warranty on the LineLazer V hydraulic pump and shortens pump life significantly.

Fusion gun grease for ProConnect and AP guns. The Graco Fusion Gun Grease Tube 4 oz (118665) is the service lubricant for the Fusion ProConnect (Fusion PC) gun moving parts on the LineLazer V 200MMA cold applied plastic units. The Fusion AP Gun Grease 3 oz (117792) is the matched grease for the Fusion Air-Purge (Fusion AP) gun. Both are plural-component-safe so they will not contaminate the resin / catalyst streams. Service per Graco interval; carry one tube on the truck for any council shift longer than three days.

Food-grade lubricant for food-processing applications. The Graco Food Grade Lubricant Grease 3 oz (117773) is NSF-certified food-grade lubricant for spray gun applications where food-grade compliance is required: food-processing facility line marking, dairy, meatworks, beverage plant. Standard non-food-grade Fusion grease is not suitable in these environments, confirm the facility compliance requirement before specifying.

End-of-shift flushing. Pump Armour 1 gallon (Graco 245133) is the standard end-of-shift flush fluid that protects the pump and packings from drying paint between shifts. Skipping Pump Armour is the single biggest cause of full-pump-rebuild service jobs on infrequent-use units. Pump Armour is currently a catalog gap on this collection, talk to us if you need it sourced through Graco AU.
