GRACO Merkur 48:1 Cart - Mount Airless Sprayer - GO Industrial - 16V175

GRACO Merkur 48:1 Cart-Mount Airless Sprayer

SKU 16U920
Afterpay Zip PayPal LeaseGO
$8,820.00
Tax included. Shipping calculated at checkout.
Configuration
Quantity
Contact for pricing
In Stock, Victoria Warehouse

Pickup available at GO Industrial

Usually ready in 1 hour

Same-day dispatch

In-stock orders by 2pm AEST

Australia-wide delivery

Direct to your job from Brisbane

Authorised service

In-house warranty + repairs

Trade pricing for all

No trade-only accounts

Product details

Built for the work it does.

Graco Merkur X48 Airless Sprayers for protective coatings are ideal for touch-ups or other smaller projects. The sprayer's light weight and portability make it a great mobile auxiliary system to finish jobs in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.

    Features

    Features

  • High-Pressure Airless Sprayers for Protective Coatings
  • Portable, lightweight (just 45kg) sprayer for a wide range of protective coatings projects and easy maneuverability
  • Compact size allows for spraying in the smallest of areas
  • Offers a unique combination of power and portability.
  • Capable of spraying medium to high solids materials at pressures up to 4800 psi (330 bar), the Merkur series handles a wide range of hot potted protective coatings applications.
  • Ideal for one-gun applications using up to 0.025 in tip
  • Affordable – get high quality results with minimal investment
  • Flexible – ideal for a wide range of applications, including marine, rail and steel fabrication
  • Compact – fits into tight areas
  • Sprays medium to higher solids coatings – up to 4800 psi (331 bar)
  • Ideal for applications such as steel fabrication, marine, rail, industrial and structural steel
  • Easy to use, easy to clean
  • Stainless steel option allows for waterborne coatings
  • The Merkur Airless Sprayer for protective coatings is ideal for touch-ups or other smaller projects. Its light weight and portability make it a great mobile auxiliary system to finish up a job in tight areas. Ideal for coatings that don’t require the pressure and flow of a larger sprayer.
    • Specifications
    COMPATIBLE MATERIAL Protective Coating
    FLUID INLET SIZE (IN) 1-1/4
    FLUID INLET SIZE (MM) 31.75
    FLUID INLET THREAD TYPE NPT
    FLUID OUTLET SIZE (IN) 3/8
    FLUID OUTLET SIZE (MM) 9.525
    FLUID OUTLET THREAD TYPE NPT
    HOSE INLET DIAMETER (CM) 0.9525
    HOSE INLET DIAMETER (IN) 3/8
    HOSE INLET DIAMETER (MM) 9.525
    INLET PAINT STRAINER 8 Mesh, 16 Mesh
    MAXIMUM SOUND PRESSURE LEVEL (DB(A)) 68.9
    MAXIMUM TIP SIZE (IN) 0.025
    MAXIMUM WORKING PRESSURE (PSI) 4800
    MAXIMUM WORKING PRESSURE (KPA) 33100
    POWER SOURCE Pneumatic
    MAXIMUM WORKING PRESSURE (MPA) 33.1
    PRESSURE CONTROL TYPE Air Regulator
    MODEL Merkur
    MAXIMUM WORKING PRESSURE (BAR) 331
    WEIGHT (KG) 45
    WEIGHT (LB) 99
    SERIES X48/X72
    PUMP TYPE Displacement Pump, Pneumatic Piston Pump
    TYPE Airless Sprayer
    MOTOR TYPE Pneumatic Motor
    PUMP SLEEVE MATERIAL Stainless Steel
    PUMP ROD TYPE Carbon Steel
    NUMBER OF GUNS 0
    MOUNT TYPE Cart Mount
    PUMP PRESSURE RATIO 48:1
    LOWER CONFIGURATION Carbon Steel;1-1/4 in. Inlet;Drain Valve
    PACKAGE OPTIONS Bare (No Hose/Gun)
    MAXIMUM AIR CONSUMPTION (SCFM) 60
    FLUID OUTLET THREAD GENDER Male
    VOLUME PER CYCLE (CM³) 75
