GO Ball Valves Actuated Electric 316 Stainless 3 Way BLS3E

SKU: BLS3T2B-E7-RT

GO Ball Valves Actuated Electric 316 Stainless 3 Way BLS3E

$616.00 AUD
$616.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
Size
Orifice

Other payment options

View full details
GO Ball Valves Actuated Electric 316 Stainless 3 Way BLS3E - GO Industrial - BLS3T2B - E7 - RT

GO Ball Valves Actuated Electric 316 Stainless 3 Way BLS3E

From $616.00 AUD
From $616.00 AUD
Save $0
Sold out

Details

Typical applications include water treatment, chemical, marine, petrochemical and general industry.

GO Ball Valves Actuated Electric 316 Stainless 3 Way BLS3E

Overview

High performance 3 way (L and T port) reduced bore 316 Stainless Steel ball valve with BSP threaded connections and a IP67 electric actuator. Self adjusting stem packing assembly with Belleville spring for temperature fluctuations and vibration. Long neck to minimise any thermal transfer from valve to actuator. Reinforced PTFE seats for temperatures up to 180°C.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Warranty

Read our complete warranty terms & conditions here.

Warranty

Read our complete warranty terms & conditions here.

Secure Payment

All our online payment methods are secured.

Secure Payment

All our online payment methods are secured.

Specifications

316 S.S 3 way, L port ball valve, with electric actuator IP67G2. RTFE seat, live loaded packing. Vacuum to 68 BAR pressure range, media temp -20°C to 180°C.OM-2-7LS 12vDC Handwheel override, extra limit switch set, visual indicator

  • Size 1/4" to 3" BSP
  • Body 316 Stainless Steel
  • Seat Reinfoced PTFE
  • Pressure 68 BAR
  • Temperature -20°C to 180°C
  • Actuation Electric
    • Model Size(BSP) Orifice (mm) Actuator Media Pressure Media Temperature
    BLS3L2B-E*-RT 1/4 8 0M-1 Vacuum to 68 Bar -20°C to 180°C
    BLS3L3B-E*-RT 3/8 10 0M-1 Vacuum to 68 Bar -20°C to 180°C
    BLS3L4B-E*-RT 1/2 12 0M-1 Vacuum to 68 Bar -20°C to 180°C
    BLS3L5B-E*-RT 3/4 15 0M-1 Vacuum to 68 Bar -20°C to 180°C
    BLS3L6B-E*-RT 1 20 0M-1 Vacuum to 68 Bar -20°C to 180°C
    BLS3L7B-E*-RT 1 1/4 25 0M-1 Vacuum to 68 Bar -20°C to 180°C
    BLS3L8B-E*-RT 1 ½ 32 0M-A Vacuum to 68 Bar -20°C to 180°C
    BLS3L9B-E*-RT 2 43 0M-2 Vacuum to 68 Bar -20°C to 180°C
    BLS3L10B-E*-RT 2 ½ 55 0M-2 Vacuum to 68 Bar -20°C to 180°C
    BLS3L11B-E*-RT 3 66 0M-3 Vacuum to 68 Bar -20°C to 180°C
