ATLAS COPCO XAS 48 KD Air Compressor 90cfm 100psi Portable Towable
- Found a better deal? Message us to price match.
Same-day dispatch
In-stock orders by 2pm AEST
Australia-wide delivery
Direct to your job from Brisbane
Authorised service
In-house warranty + repairs
Trade pricing for all
No trade-only accounts
The Atlas Copco XAS 48 KD is a portable, towable diesel air compressor from the 8 Series range, delivering 90 CFM (2,5 m3/min) of free air at a working pressure of 100 psi (7 bar). It is light enough to tow behind a standard passenger car without a special licence, with a full size fuel tank, after-cooler and generator built into a compact and lightweight package that can be up to 150kg lighter than comparable models.
Power comes from a three cylinder Kubota D 902 diesel engine, and the unit is protected by the Hard Hat canopy with a three layer C3 anti-corrosion coating for long life and strong resale value.
Features
Starter Protection: Starter motor protection system guards the starter against overheating.
Anti-Corrosion Paint: Three layer anti-corrosion (C3) paint system.
Anti Air Lock: Anti air lock system for guaranteed starting.
Battery Cut-Off: Battery cut off switch isolates the battery.
Spillage Free Frame: Seamless single sheet frame contains all fluids for better durability.
Kubota Engine: Reliable, high performance Kubota diesel engine.
Hard Hat Canopy: The legendary Hard Hat canopy protects the internal components.
Encased Wiring: Encased wire routings for extra protection.
Included accessories
Specifications
| Model | XAS 48 Kd |
|---|---|
| Working Pressure | 7 bar (100 psi) |
| Free Air Delivery | 90 CFM (2,5 m3/min) |
| Noise Sound Pressure (Lp) | 70 dB(A) |
| Noise Sound Power (Lw) | 98 dB(A) |
| Max. Ambient Temperature At Sea Level | 50 degrees C |
| Min. Starting Temperature | -10 degrees C |
| Min. Starting Temperature (cold start aid) | -20 degrees C |
| Engine Brand | Kubota |
| Engine Model | D 902 |
| Number Of Cylinders | 3 |
| Power Output | 18,5 kW |
| Full Load RPM | 3600 rpm |
| Unload RPM | 2000 rpm |
| Engine Oil Capacity | 3,6 L |
| Compressor Oil Capacity | 5,5 L |
| Fuel Tank Capacity | 27 L |
| Box Unit Dimensions (L x W x H) | 1570mm (towbar down) x 1060mm x 990mm |
| Box Unit Weight | 440 kg |
| Trolley Dimensions (L x W x H) | 1960mm x 1230mm x 1250mm |
| Trolley Weight | 500 kg |
