ATLAS COPCO XAS 48 KD Air Compressor 90cfm 100psi Portable Towable
- Found a better deal? Message us to price match.
Same-day dispatch
In-stock orders by 2pm AEST
Australia-wide delivery
Direct to your job from Brisbane
Authorised service
In-house warranty + repairs
Trade pricing for all
No trade-only accounts
Built for the work it does.
The 8 series is the latest product launched in-line with the Forward-Thinking philosophy of the Portable Energy division
What do you tow?
The new Atlas Copco 8 Series compressor range, from GO Industrial, is the result of over a decade of continuous development. For the first time, it’s possible to transport behind a normal passenger car, with no special driving license, a compressor that can produce up to 5 m3 /min of air, with a full size fuel tank, after-cooler and generator all incorporated into a compact and lightweight package.
This is all made possible by the latest development in our pioneering air element design, meaning we can produce a compressor up to 150kg lighter than comparable models. However, we understand that this means nothing without efficiency. Efficiency can mean many things, such as: reduced service time, fuel consumption or increased utilisation.
The 8 Series ticks all the boxes when it comes to delivering outstanding performance in all of these categories. Lastly, depending on your application you might ask about robustness, durability, ruggedness or toughness – we have one simple word for all of the above – The HardHat®.
This legendary canopy was born in 2005 and the 8 Series features the latest, toughest design. The amazing new 8 Series from Atlas Copco, it’s all about the numbers, it’s all about changing the game and we have one clear challenge to you – what do you tow?
Features
Features
Standard Features Summary
Specifications
- Working Pressure: 100psi (g)
- Free Air Delivery: 90CFM
- Max Sound Pressure Level @ 7m: 70dB (A)
- Engine: Kubota D 902
- Fuel Tank Capacity: 27 L
Performance
| Model | XAS48Kd | |
| Working Pressure | bar(g) | 7 |
| Psi(g) | 100 | |
| Free Air Delivery | CFM | 90 |
| m3/min | 2,5 | |
| Output power | kVA | - |
| Noise sound pressure (Lp) | dB (A) | 70 |
| Noise sound power (Lw) | dB (A) | 98 |
| Max. ambient temperature at sea level | degrees celsius (c) | 50 |
| Min. Starting temperature |
|
-10 |
| Min. Starting temperature (cold start aid) |
|
-20 |
Engine
|
Brand |
Kubota |
|
|
Model |
D 902 |
|
|
Number of cylinders |
3 |
|
|
Power Output |
kW |
18,5 |
|
Full Load RPM |
rpm |
3600 |
|
Unload RPM |
rpm |
2000 |
| Engine Oil Capacity | l | 3,6 |
| Compressor oil capacity | l | 5,5 |
| Fuel tank capacity | l | 27 |
Dimensions and Weight: XAS 48 Kd box unit
|
Length, towbar down |
mm |
1570 |
|
Width |
mm |
1060 |
|
Height |
mm |
990 |
|
Weight |
kg |
440 |
Dimensions and Weight : Trolley
|
Length |
mm |
1960 |
|
Width |
mm |
1230 |
|
Height |
mm |
1250 |
|
Weight |
kg |
500 |
