ATLAS COPCO U190 PACE Utility Series 8 Air Compressor
- Found a better deal? Message us to price match.
Same-day dispatch
In-stock orders by 2pm AEST
Australia-wide delivery
Direct to your job from Brisbane
Authorised service
In-house warranty + repairs
Trade pricing for all
No trade-only accounts
Built for the work it does.
The U 190 PACE portable air compressor delivers 90-190CFM free air delivery and 70-150psi (g) normal effective working pressure.
Thanks to its PACE (Pressure Adjust through Cognitive Electronics) system, operators are able to choose from the widest operating pressure range currently available for a truck-mounted air compressor. With the PACE electronic regulation system, operators use a simple-to-use digital controller to adjust the pressure with pinpoint accuracy depending on their application need.
The 8 Series Utility range is light weight, compact package. This range may not have any wheels, but all the integrated features mean we are proud to call this a mobile, easy to move compressor.
All 8 Series compressors are under 750 kg and service can always be completed under one hour. The Utility range offers models with our revolutionary PACE system. PACE enables you to control the pressure and regulate the flow – giving you even more versatility to handle the toughest applications. All models come with a corrosion free C3 rated canopy.
Features
Features
Specifications
Performance
|
Normal effective working pressure |
bar(g) |
5-10,5 |
|
Normal Effective working pressure |
psig |
70-150 |
|
Actual free air delivery |
cfm |
90-190 |
| Max. ambient temperature at sea level | degrees celsius | 50 |
| Min. starting temperature/ cold start kit | degrees celsius | -10/-20 |
Engine
|
Make |
Kubota |
|
Type |
V1505T |
|
Number of cylinders |
4 |
|
Output at rated speed |
32,5 kW |
| Engine Speed (nominal) | 3000 rpm |
| Engine speed (unloaded) | 1600 rpm |
| Capacity engine oil system | 5,5L |
| Capacity compressor oil | 9L |
| Fuel Tank | 62L |
| Cooling system | 8,5L |
Dimensions
| Length (including - fixed tow bar) | 1870mm |
| Width | 950mm |
| Height | 1040mm |
| Weight | 704 kgs |
Shipping & Returns
Same-day dispatch from one of our national warehouses on in-stock orders placed before 2pm AEST.
30-day returns on unopened, stocked items — customer pays return freight. Non-stocked / special-order items are subject to a 50% restocking fee.
