GO Actuators Pneumatic Double Acting

SKU: DA32

GO Actuators Pneumatic Double Acting

$121.00 AUD
$121.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
Range

Other payment options

View full details
GO Actuators Pneumatic Double Acting - GO Industrial - DA32

GO Actuators Pneumatic Double Acting

From $116.00 AUD
$121.00
Sold out

Details

Options include IP67 limit switch box with visual Indicator, Namur (direct mount) solenoid valves and a range of inserts to step the drive down.

GO Actuators Pneumatic Double Acting

Overview

Incorporates the latest mechanical technology (rack and pinion design) to give long service life with light weight and high performance. Features include end of stroke adjustment, namur interface, visual Indicator and ISO mounting interface.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Warranty

Read our complete warranty terms & conditions here.

Warranty

Read our complete warranty terms & conditions here.

Secure Payment

All our online payment methods are secured.

Secure Payment

All our online payment methods are secured.

Specifications

Model Air supply pressure (bar)
2.5 3 4 5 5.5 6 7 8
Torque output double acting actuators (NM)
DA 32 3.5 4.2 6 7.5 8 9 10 11.5
DA 50 8.3 10 13.3 16.6 18.3 19.9 23.3 26.6
DA 63 14.7 17.6 23.5 29.3 32 35.2 41 46.9
DA 75 29 35 46.5 58.2 64 70 82 93
DA 88 45.8 54.9 73.2 91.5 101 110 128 146
DA 100 66 79.8 106 133 146 160 186 213
DA 115 107 129 172 215 236 258 301 344
DA 125 138 166 222 277 305 332 388 443
DA 145 217 261 348 435 478 522 609 696
DA 160 284 340 454 567 624 681 794 908
DA 180 383 459 613 766 842 919 1072 1225
DA 200 532 638 851 1064 1170 1276 1489 1702
DA 240 1160 1392.5 1857 2321 2553 2785 3249 3713
DA 270 1550 1860 2480 3100 3410 3720 4341 4961





      Air Consumption in Litres (1 litre = 1000cm³)

      Model (DA) 32 50 63 75 88 100 115 125 160 200 270
      Consumption 0.038 0.108 0.199 0.266 0.495 0.743 1 1.751 3.606 5.704 15
      To work out L/min multiply the value in the table by the number of strokes in a minute.
      • Size 32mm to 270mm
      • Body Anodised Aluminium
      • End Caps Epoxy coated aluminium
      • Pinion Nickel Plated Steel
      • Fixings 316 Stainless Steel
      • Actuation Double Acting Pneumatic
