Details

Typical Applications include: Petrochemical, diesel farms, vacuum packaging, tank drain or low pressure service & general industry.

GO B55 Brass Petrochemical Direct Acting Normally Closed Solenoid Valves

Overview

A direct acting normally closed (power to open) brass forged body solenoid valve with a stainless steel operator. Suitable for low head and zero head applications. available in various seat materials including Viton (standard), Silicone, Neoprene, EPDM & Nitrile (contact us for any seals other than standard). Liquids to 40cst viscosity. Standard coil is weatherproof to IP65 and has LED illuminated plug.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Warranty

Read our complete warranty terms & conditions here.

Warranty

Read our complete warranty terms & conditions here.

Secure Payment

All our online payment methods are secured.

Secure Payment

All our online payment methods are secured.

Specifications

Brass 2 way 2 position normally closed direct acting solenoid valve.G1/4", 3mm orifice, 304 SS operator, copper shading ring, FKM seat.0-10 BAR pressure range, vacuum 27"Hg, media temp -10°C to 100°C.Coil Class H insulation, 12 Watts DC, IP65 protection.

  • Size 1/4" to 1/2" BSP
  • Function Normally Closed (power to open)
  • Valve Operation Direct Acting
  • Body Forged Brass
  • Seat FKM
  • Pressure Range 0 to 10 BAR
  • Media Petrochemical
Model Port Size BSP Orifice ømm CV Pressure (BAR) Media Temperature Coil Specifications
B55-2-3-*V 1/4" 3 0.26 0 to 10 -10°C to 100°C SC-C1
12 Watts
15 Volta Amps
Class H Insulation
B55-2-4-*V 1/4" 4 0.58 0 to 7 -10°C to 100°C
B55-2-5-*V 1/4" 5 0.64 0 to 5 -10°C to 100°C
B55-3-4-*V 3/8" 4 0.58 0 to 10 -10°C to 100°C SC-C2
18 Watts
24.4 Volt Amps
Class H Insulation
B55-3-6-*V 3/8" 6 0.79 0 to 5 -10°C to 100°C
B55-3-8-*V 3/8" 8 0.97 0 to 2 -10°C to 100°C
B55-4-6-*V 1/2" 6 0.79 0 to 5 -10°C to 100°C
B55-4-8-*V 1/2" 8 0.97 0 to 2 -10°C to 100°C
