Graco 30:1 Merkur Pump Fluid Flow Wall Mount
  • Graco 30:1 Merkur Pump Fluid Flow Wall Mount
1 1

Technical Specifications

CONVERTIBLE Non-Convertible
FLUID INLET SIZE (IN) 1/2
FLUID INLET SIZE (MM) 12.7
FLUID INLET THREAD TYPE NPT
FLUID OUTLET SIZE (IN) 3/8
FLUID OUTLET SIZE (MM) 9.525
FLUID OUTLET THREAD TYPE NPT
HOSE INLET DIAMETER (CM) 0.47625
HOSE INLET DIAMETER (IN) 3/16
HOSE INLET DIAMETER (MM) 4.7625
INCLUDES 仅适用于泵的空气控制器, ポンプ用エア制御, Pump Only Air Controls, Pump Only Air Controls, Commandes pneumatiques de la pompe uniquement, Controles de bombeo solamente de aire, 펌프 에어 제어장치, Pumpensteuerung (nur Luft), Luchtregelaars voor pomp, Comandi pneumatici solo pompa
MAXIMUM FLOW RATE (GPM) 0.40
MAXIMUM FLOW RATE (L/MIN) 1.5
MAXIMUM HOSE LENGTH (FT) 25
MAXIMUM HOSE LENGTH (M) 7.5
MAXIMUM WORKING PRESSURE (PSI) 3000
MAXIMUM WORKING PRESSURE (KPA) 20700
POWER SOURCE Air
MAXIMUM WORKING PRESSURE (MPA) 20.7
MODEL Merkur
MAXIMUM WORKING PRESSURE (BAR) 207
WEIGHT (KG) 15
WEIGHT (LB) 34
PUMP TYPE Pneumatic Piston Pump
TYPE Bare Package
MOTOR TYPE Pneumatic
MAXIMUM WORKING PRESSURE (KG/CM²) 210.9
WETTED MATERIAL Stainless Steel, Tungsten Carbide with 6% Nickel, UHMWPE, PTFE, Nylon
NUMBER OF GUNS 0
PRESSURE TYPE High Pressure
MOUNT TYPE Wall Mount
GUN TECHNOLOGY Bare Package
GUN TYPE No Applicator
GUN INCLUDED 0
GUN MODEL No Applicator
PUMP RATIO 30:1
PRODUCT TYPE Bare Package
  • Proven to outperform and outlast other pumps in their class
  • Highest technology air motor on the market
  • Low air consumption for increased efficiency
  • Muffler provides low operating noise levels
  • External valve access allows for easy servicing and online replacement to minimise downtime
  • Operator control panel located at operator height for easy setting and monitoring
  • Throat seal and rod enclosure protects pumped material and wet cup from contamination, but can be easily removed to monitor and service

Graco 30:1 Merkur Pump Fluid Flow Wall Mount

SKU: G30W01

Graco 30:1 Merkur Pump Fluid Flow Wall Mount

$6,611.00 AUD
$6,611.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
Size

Other payment options

The Basics

Merkur fine finish pump packages are designed to improve productivity, reduce costs, lower emissions and provide consistent, high-quality finishes for all of your demanding applications.

Technical Specifications

CONVERTIBLE Non-Convertible
FLUID INLET SIZE (IN) 1/2
FLUID INLET SIZE (MM) 12.7
FLUID INLET THREAD TYPE NPT
FLUID OUTLET SIZE (IN) 3/8
FLUID OUTLET SIZE (MM) 9.525
FLUID OUTLET THREAD TYPE NPT
HOSE INLET DIAMETER (CM) 0.47625
HOSE INLET DIAMETER (IN) 3/16
HOSE INLET DIAMETER (MM) 4.7625
INCLUDES 仅适用于泵的空气控制器, ポンプ用エア制御, Pump Only Air Controls, Pump Only Air Controls, Commandes pneumatiques de la pompe uniquement, Controles de bombeo solamente de aire, 펌프 에어 제어장치, Pumpensteuerung (nur Luft), Luchtregelaars voor pomp, Comandi pneumatici solo pompa
MAXIMUM FLOW RATE (GPM) 0.40
MAXIMUM FLOW RATE (L/MIN) 1.5
MAXIMUM HOSE LENGTH (FT) 25
MAXIMUM HOSE LENGTH (M) 7.5
MAXIMUM WORKING PRESSURE (PSI) 3000
MAXIMUM WORKING PRESSURE (KPA) 20700
POWER SOURCE Air
MAXIMUM WORKING PRESSURE (MPA) 20.7
MODEL Merkur
MAXIMUM WORKING PRESSURE (BAR) 207
WEIGHT (KG) 15
WEIGHT (LB) 34
PUMP TYPE Pneumatic Piston Pump
TYPE Bare Package
MOTOR TYPE Pneumatic
MAXIMUM WORKING PRESSURE (KG/CM²) 210.9
WETTED MATERIAL Stainless Steel, Tungsten Carbide with 6% Nickel, UHMWPE, PTFE, Nylon
NUMBER OF GUNS 0
PRESSURE TYPE High Pressure
MOUNT TYPE Wall Mount
GUN TECHNOLOGY Bare Package
GUN TYPE No Applicator
GUN INCLUDED 0
GUN MODEL No Applicator
PUMP RATIO 30:1
PRODUCT TYPE Bare Package
  • Proven to outperform and outlast other pumps in their class
  • Highest technology air motor on the market
  • Low air consumption for increased efficiency
  • Muffler provides low operating noise levels
  • External valve access allows for easy servicing and online replacement to minimise downtime
  • Operator control panel located at operator height for easy setting and monitoring
  • Throat seal and rod enclosure protects pumped material and wet cup from contamination, but can be easily removed to monitor and service
