GRACO RoadLazer RoadPak System - GO Industrial - 25D268

GRACO RoadLazer RoadPak System

SKU 25D268
Afterpay Zip PayPal LeaseGO
$111,000.00
Tax included.
Size
Quantity
Contact for pricing
No stock main warehouse, contact for lead time

Get a shipping estimate

The same live rates you'll see at checkout, for this item.

GRACO RoadLazer RoadPak System · Qty 1

Estimate inc GST for this item plus anything already in your cart. Your final rate is confirmed at checkout.

Need it palletised or delivered to site? Chat with us.

Calculate your LeaseGO repayments

Spread the cost over 24, 36 or 48 months with simple monthly payments.

Business customers only. LeaseGO finance is available to businesses with an active ABN. It isn't available for personal or household purchases.

$
Pick a term that suits your cash flow
24 months
Per month-
Per week-
Per day-
36 months
Per month-
Per week-
Per day-
48 months
Per month-
Per week-
Per day-

Terms and conditions apply, subject to suitability assessment. Prices quoted are indicative only and payable monthly in advance over the chosen term. $99 Establishment Fee payable upon commencement ($79 under $1,500). Visit LeaseGo.com.au to learn more.

Scan or click here to apply now with LeaseGo

Apply in minutes with your mobile, licence and ABN, then give your approval number to the GO team.

Apply now
LeaseGo application QR code

Dispatch options

GO stock or Melbourne supplier stock

Australia-wide delivery

Delivery to your job site

Authorised service

In-house warranty + repairs

Trade pricing for all

No trade-only accounts

Product details

With its modular design, the Graco RoadLazer RoadPak System is designed to be as easy to use as a walk-behind striper with high production speeds normally only found on Long Line trucks. Comes standard with 1 pressurised bead tank then just choose the type of gun arm mounting frame you require as well as other accessories to design your own unit.

Configurations

OPTION 1: 25M701 1 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M708 1 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G634 RoadPak Pointer System

OPTION 2: 25M701 1 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M708 1 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G633 RoadView Camera System, 24G634 RoadPak Pointer System

OPTION 3: 25M701 1 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M708 1 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G634 RoadPak Pointer System, 25M712 Steerable Carriage, 25M713 Winch Kit, 25M716 Seat Kit

OPTION 4: 25M701 1 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M708 1 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G633 RoadView Camera System, 24G634 RoadPak Pointer System, 25M712 Steerable Carriage, 25M713 Winch Kit, 25M716 Seat Kit

OPTION 5: 25M703 2 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G634 RoadPak Pointer System

OPTION 6: 25M703 2 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G633 RoadView Camera System, 24G634 RoadPak Pointer System

OPTION 7: 25M703 2 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G634 RoadPak Pointer System, 25M712 Steerable Carriage, 25M713 Winch Kit, 25M716 Seat Kit

OPTION 8: 25M703 2 Pump RoadPak (450 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G633 RoadView Camera System, 24G634 RoadPak Pointer System, 25M712 Steerable Carriage, 25M713 Winch Kit, 25M716 Seat Kit

OPTION 9: 25M704 2 Pump RoadPak (1350 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G634 RoadPak Pointer System

OPTION 10: 25M704 2 Pump RoadPak (1350 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G633 RoadView Camera System, 24G634 RoadPak Pointer System

OPTION 11: 25M704 2 Pump RoadPak (1350 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G634 RoadPak Pointer System, 25M712 Steerable Carriage, 25M713 Winch Kit, 25M716 Seat Kit

OPTION 12: 25M704 2 Pump RoadPak (1350 lb. Bead Tank), 24G627 RoadPak Slide in Mounting Frame, 25M709 2 Pump RoadPak Gun Arm, 25M711 RoadLazer/RoadPak Control, 24G633 RoadView Camera System, 24G634 RoadPak Pointer System, 25M712 Steerable Carriage, 25M713 Winch Kit, 25M716 Seat Kit



Features

Features

Road Pak Pump System

Heavy-Duty RPS 2900 Hydraulic System

  • No-stall design provides unmatched productivity
  • Maximum pressure of 200 bar

Proven Displacement Pump System

  • Delivering outstanding results in pumping paint for decades
  • Prime valve allows you to recirculate paint keeping it mixed and ready to go

Bead Tank System

  • ASME rated and can drop at a rate of up to 18 kg per minute
  • Easier material loading with large fill spout opening

Road Pak 1-Pump/2-Gun Arm

  • Fast set-up, high output
  • 3 Gun capacity
  • No-tools gun adjustments

Advanced Controller

  • Less Setup Time
  • Built-in advanced patterns for quick recall
  • Pattern preview gives a quick visual of colors and patterns selected
  • Export capabilities allows for “proof of job”

Heavy-Duty Modular Frame System

  • Heavy-duty steel frame is built to last
  • Simple to add the options you want in minutes - optimizing your striping system
  • Small frame size allows it to fit almost anywhere - from the back of a pickup or flatbed truck to the bed of a utility vehicle

Heavy-Duty Compressor

  • 100 psi (6.9 bar) at 13.1 cfm (0.37 m³/min)
  • Accumulation tank supports up to 5 airless paint guns and 5 bead guns

Kohler® Power

  • 19 HP (14.2 kW) Kohler engine
  • Over 15 years of reliable experience
Specifications
BEAD SYSTEM Pressurized Bead System
ENGINE BRAND Kohler
INCLUDES RoadPak Advanced Controller, RoadPak HD 2, RoadPak 2 Gun Arm, Slide-in Mounting Frame, Simple Guide System
MAXIMUM FLOW RATE (GPM) 5
MAXIMUM FLOW RATE (L/MIN) 18.9
MAXIMUM SOUND PRESSURE LEVEL (DB(A)) 91.7
MAXIMUM WORKING PRESSURE (BAR) 200
MAXIMUM WORKING PRESSURE (KPA) 2000
MAXIMUM WORKING PRESSURE (PSI) 2900
MODEL RoadLazer
NUMBER OF GUNS 2
NUMBER OF PUMPS 1
POWER RATING (HP) 19
POWER RATING (KW) 14.2
SERIES RoadPak
TYPE Truck-Mounted Line Striper
BEAD TANK SIZE (LB) 450
MOUNT TYPE Slide-In Mounting Frame
Warranty

1 year warranty on all components - pump, gun, motor or engine, drive system, frame, electronics, factory-fitted hoses.
