GRACO Viscount II 2.4:1 Ratio Hydraulic Pump

SKU: 222902

GRACO Viscount II 2.4:1 Ratio Hydraulic Pump

$22,770.00 AUD
$22,770.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.

Other payment options

View full details
GRACO Viscount II 2.4:1 Ratio Hydraulic Pump | GO Industrial

GRACO Viscount II 2.4:1 Ratio Hydraulic Pump

$22,770.00 AUD
$22,770.00 AUD
Save $0
Sold out

Details

Compatible Material

  • Grease

Features

  • Built-In Reliability - Self-lubricating vertical design for long life and reliable operation in high-vibration environments.
  • Quiet Hydraulic Motor - No need for add-on mufflers.
  • High-Efficiency Motor - Uses less hydraulic oil.

    • Graco Viscount II 2.4:1 Ratio Hydraulic Pump

    Overview

    Field-Proven, Energy-Efficient. When paired with any of Graco’s priming piston pumps, the Viscount II hydraulic motor offers exceptional cost savings by operating on 20% of the energy used by a pneumatic motor.

        Shipping & Returns

        Our network of warehouses Australia-wide enables us to
        deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

        All returns must be pre-approved to ensure replacement and / or refund.

        Shipping & Returns

        Our network of warehouses Australia-wide enables us to
        deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

        All returns must be pre-approved to ensure replacement and / or refund.

        Warranty

        Read our complete warranty terms & conditions here.

        Warranty

        Read our complete warranty terms & conditions here.

        Secure Payment

        All our online payment methods are secured.

        Secure Payment

        All our online payment methods are secured.

        • 308149EN-T - Check-Mate 2100 Pumps
        • Graco Viscount II Pumps - GO Industrial

        Specifications

      • Fluid Pressure Ratio: 2.4:1
      • Maximum Input Pressure: 1,500 psi (103.5 bar)
      • Maximum Fluid Input Volume: 12 gpm (45.4 lpm)
      • Maximum Output Flow Rate: 7.5 gpm (28.5 lpm)
      • Maximum Recommended CPM: 60
      • Maximum Fluid Output Pressure: 2,300 psi (159 bar)
        • TYPE Hydraulic Piston Pump
        APPLICATION Bonding, Sealing, Gasketing, Potting, Encapsulation, Molding, Spray, Fluid Transfer, Unloading, Underfill
        FLUID OUTLET SIZE (IN) 1-1/2
        FLUID OUTLET THREAD GENDER Male
        FLUID OUTLET THREAD TYPE NPT
        MATERIAL Carbon Steel
        MAXIMUM CONTINUOUS CYCLE RATE (CPM) 60
        MAXIMUM FLOW RATE (GPM) 7.5
        MAXIMUM FLOW RATE (L/MIN) 28.4
        MAXIMUM HYDRAULIC FLUID INLET PRESSURE (BAR) 103
        MAXIMUM HYDRAULIC FLUID INLET PRESSURE (KPA) 10300
        MAXIMUM HYDRAULIC FLUID INLET PRESSURE (PSI) 1500
        MAXIMUM OPERATING TEMPERATURE (°C) 66
        MAXIMUM OPERATING TEMPERATURE (°F) 150
        MAXIMUM WORKING PRESSURE (BAR) 159
        MAXIMUM WORKING PRESSURE (KPA) 15900
        MAXIMUM WORKING PRESSURE (PSI) 2300
        MODEL Viscount
        PORTABLE Non-Portable
        POWER TYPE Hydraulic
        PUMP RATIO 2.4:1
        SERIES II
        MAXIMUM WORKING PRESSURE (MPA) 15.9

          Features

        • Built-In Reliability - Self-lubricating vertical design for long life and reliable operation in high-vibration environments.
        • Quiet Hydraulic Motor - No need for add-on mufflers.
        • High-Efficiency Motor - Uses less hydraulic oil.
