Brady BBP72 Double Sided Label Printer

SKU: 104549

$15,180

Brady BBP72 Double Sided Label Printer

DATA SHEET
USER MANUAL
WARRANTY



The BBP72 from Brady is a thermal transfer double-sided sleeve printer. The BBP72 is a timesaving printer since printing both sides of the sleeve happens simultaneously, which satisfies the growing need of customers to have information on both sides.

Overview BBP72

The BBP®72 Double-Sided Printer is the ideal solution for creating two-sided heat shrink sleeve labels for wire and cable identification.

  • The BBP®72 Double-Sided Printer is designed with two print heads to print on both the top and bottom of the sleeves simultaneously
  • Double-sided printing eliminates the time-consuming, tedious process of re-winding and re-printing
  • Ideal for large print run quantities with automatic printing and formatting to reduce label errors
  • Includes LabelMark® Standard Software and the free Brady360® 5 year warranty

Specifications BBP72

Automatic Label Set Up No
Barcode Capability Barcode Capable
Color Printing Capability Single Color
Custom Media Parts Available Yes
Dimensions 395mm H x 255mm W x 550mm D
UOM Kit
Maximum Printed Label Length 1980mm
Maximum Label/Tape Width 100mm
Maximum Liner Width 110mm
Maximum Print Speed 125 mm/s
Maximum Print Width 105mm
Minimum Label Length 20mm
Minimum Liner Width 4mm
Power Supply Voltage 100 to 240 V @ 50 to 60 Hz
Print Multiple Copies Yes
Print Preview Feature? No
Print Resolution 300 dpi
Product Number 104549
UPC 662820801740
Ribbon Ink Wind Direction Side In/Side Out
Trade Name BBP®72
Warranty 5 Years
Applications Double Sided Sleeve Printing, Single Sleeve Printing
Barcode Symbologies - Linear 128 A, B, C, Codabar, Code 39, Code 93, EAN 8,13, EAN/UCC 128, EAN/UPC Appendix 2, EAN/UPC Appendix 5 Plessey, FIM, Full ASCII Ident and Lead Code of Code Deutsche Post AG, HIBC, Interleaved 2 of 5 Code 39, JAN 8,13, MSI, PostNet, RSS 14, UPC A,E,E0
Barcode Symbologies - 2D Aztec, Codablock F, Data Matrix, EAN Data Matrix, GS1 Data Bar, Limited, Micro PDF 417, PDF 417, QR Code, RSS 14 Truncated, Stacked, Stacked Omnidirectional, UPS MaxiCode
Label Material Types Polyolefin
Connectivity Options Ethernet, Parallel, Serial, USB
Continuous & Die-Cut Materials Supported Continuous Tapes & Die-Cut Labels
Desktop Printer Model BBP®72 Label Printer
Display Type LCD
Font Styles Arial, Courier New, Tahoma, Times New Roman, Trechuchet MS, Verdana
Includes CD ROM, Power Cable
Keyboard Type None
Kits Available No
Label/Media Format Roll
Built-In Label Wizards No
Languages Available Arabic Dutch, Bulgarian, Croatian, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Italian, Lithuanian, Macedonian, Mexican-Spanish, Norwegian, Polish, Portuguese, Romanian, Russian, Serbian, Slovenian, Spanish, Swedish, Turkish
Material Polyvinylidene Fluoride
Maximum Labels per Day 7000
Media Sensor Type Gap Sensor, Reflective Sensor
Memory 64 MB
Mode of Operation Peripheral Mode
Plug Type EU, UK, US
Print Technology Thermal Transfer
