GO CI Body 316 SS Disc EPDM Liner BFLSR Butterfly Valves Actuated Spring Return Pneumatic Lugged

SKU: BFL550-SR

GO CI Body 316 SS Disc EPDM Liner BFLSR Butterfly Valves Actuated Spring Return Pneumatic Lugged

$253.00 AUD
$253.00 AUD
Inclusive of GST. Shipping calculated at checkout.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
Size
Seat
Flange

Other payment options

GO CI Body 316 SS Disc EPDM Liner BFLSR Butterfly Valves Actuated Spring Return Pneumatic Lugged

Overview

The BFL series of lugged butterfly valves (table E standard) have a cast iron body, 316 S.S disc and an EPDM seat making them suited to a wide range of general water and industrial applications. They are operated by either a high quality anodised aluminium spring return(rack and pinion design) pneumatic actuator. This allows the valve to return to a fail safe position should air be lost. The unique bonded cartridge design of the valve gives it a longer life span, allows vacuum to be run through it and makes it replaceable if ever the need should arise.

        Details

        Common applications include water trucks, irrigation, cement hoppers and other industrial applications. If sizes above 300mm, different flange standards or different seat materials are required please contact us.

        Specifications

      • Size 50mm to 300mm
      • Body FBE coated Cast Iron
      • Seat EPDM
      • Disc 316 Stainless Steel
      • Pressure 16 BAR
      • Actuation Spring Return Pneumatic
        • Model Size (mm) Actuator Media Pressure Media Temperature Actuator Pressure
        BFL550-SR-E 50 SR63 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL565-SR-E 65 SR63 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL580-SR-E 80 SR75 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL5100-SR-E 100 SR88 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL5125-SR-E 125 SR88 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL5150-SR-E 150 SR115 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL5200-SR-E 200 SR125 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL5250-SR-E 250 SR145 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
        BFL5300-SR-E 300 SR160 Vacuum to 16 BAR -20°C to 120°C 6 to 8 BAR
