GO Pressure Gauge 150mm 1/2" NPT Bottom Entry 316 SS GAU150BS Range
SKU: GAU150BS-1000
$165
GO Pressure Gauge 150mm 1/2" NPT Bottom Entry 316 SS GAU150BS Range
Full Stainless Steel 150mm glycerine filled pressure gauge with stainless steel internals and entry. Crimped ring housing with polycarbonate window. Dual scale kpa/psi. Accuracy +-1.0% of full scale. Operating temp of -20°C to 60°C. For use on compatible gases and liquids. Comes with back mounting flange.
- Pressure Range 0 kpa to 2500 kpa
- Body Stainless Steel
- Function Dual Scale Kpa/PSI glycerine filled pressure gauge
- Connection 1/2" NPT Bottom Entry
- Factory Accredited CE, ISO 9001, TUV
| Model | Range |
|---|---|
| GAU150BS~1000 | 0 to 1000 kpa |
| GAU150BS~2500 | 0 to 2500 kpa |
| Size | 150mm (6") |
| Accuracy | +/- 1.0% |
| Range | Depends upon model |
| Work Pressure | 3/4 of full scale |
| Fluctuating pressure | 2/3 of full scale |
| Short Time Pressure | Full Scale |
| Operating Temperature | -10°C to 60°C |
| Media | Compatible gases and liquids |
| Housing | 316 Stainless Steel Case with Bayonnet Bezel |
| Window | Polycarbonate |
| Liquid Filled | Glycerine |
| Bourdon Tube | 316 Stainless Steel |
| Movement | 316 Stainless Steel |
| Connection | 316 Stainless Steel |
| Thread | 1/2" NPT |
| Scale | Dual Scale Kpa/Psi |
