GO Pressure Switch Plated Steel PSP Range
Dimensions - GO Pressure Switch Plated Steel PSP Range
Wiring Diagram - GO Pressure Switch Plated Steel PSP Range
  • GO Pressure Switch Plated Steel PSP Range
  • Dimensions - GO Pressure Switch Plated Steel PSP Range
  • Wiring Diagram - GO Pressure Switch Plated Steel PSP Range
1 4

GO PSP Pressure Switch Plated Steel

SKU: PSP150R14S

GO PSP Pressure Switch Plated Steel

$209.00 AUD
$209.00 AUD
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
stock
In Warehouse. Ready to ship or collect in 3 to 7 days. Delivery times vary as per courier.
Pressure Range

Other payment options

View full details
GO Pressure Switch Plated Steel PSP Range

GO PSP Pressure Switch Plated Steel

From $209.00 AUD
From $209.00 AUD
Save $0
Sold out

Details

Typical Uses Include:

  • Pneumatic
  • Hydraulic
  • Lubrication
  • General Industry

GO PSP Pressure Switch Plated Steel

Overview

Adjustable pressure switch which are single pole double throw meaning they can be wired normally closed or normally open. Electrical connection is by an IP65 DIN plug (PG9) and port connection is a 1/4" BSP parallel thread with an o-ring gasket.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Shipping & Returns

Our network of warehouses Australia-wide enables us to
deliver anywhere in Australia except to PO Boxes. We aim to ship your order within 1-3 days upon receipt of payment, as long as the item is readily available.

All returns must be pre-approved to ensure replacement and / or refund.

Warranty

Read our complete warranty terms & conditions here.

Warranty

Read our complete warranty terms & conditions here.

Secure Payment

All our online payment methods are secured.

Secure Payment

All our online payment methods are secured.

Specifications

  • Switching Range 30 to 300 BAR
  • Body Stainless Steel
  • Function Single Pole Double Throw (SPDT)
  • Voltage Multi Voltage (0 to 240v AC/DC)
  • Current 6 amp resistive and 2 amp inductive
  • Factory Accredited CE, ISO 9001, TUV
    • Model Adjustment Range (BAR) Max Over Pressure (bar) Body Material Piston Seal Material Snubber Repeatability (BAR) Weight (grams)
    PSP150R14S 30-150 600 Pl. Steel NBR Yes ±5 100
    PSP300R14S 50-300 600 Pl. Steel NBR Yes ±15 100
