Graco RAC X Fine Finish Low Pressure Switch Tip Range

• Breakthrough low-pressure SmartTip Technology engineered to deliver the industry's best finish.
• Featuring the patented Graco RAC X Tip with SmartTip Technology and exclusive internal tip geometry which delivers the industry's best finish at low airless spray pressure!
• SmartTip Technology is designed to work with Graco's exclusive SmartControl Pressure Management System to deliver a superior spray fan without pressure fluctuations – at all spraying pressures!

Industry's best finish at low airless spray pressure!

• Sprays at up to 50% lower pressure with less overspray to provide consistent blended finish quality with complete atomization

• Soft spray fan pattern makes it easy to apply any material to any surface
• Featuring patent-pending SmartTip Technology, Graco's exclusive internal tip geometry reduces the energy required to atomize your favourite paints, stains, and other materials – delivering a superior finish with less pressure
• Spraying at half pressure doubles tip life
• Reduces prep and cleanup – you put the paint where you want it
• Works with any airless sprayer

• Now available in 6 additional sizes for large surface and high production application

FAN WIDTH	Inch (mm)	0.008	0.010	0.012	0.014	0.016	0.018	0.020
2-4 (51-102)	108	110	112	-	-	-	-
4-6 (102-152)	208	210	212	214	-	-	-
6-8 (152-203)	308	310	312	314	-	-	-
8-10 (203-254)	-	410	412	414	-	-	-
10-12 (254-305)	-	510	512	514	516	518	520
12-14 (305-356)	-	-	-	-	616	618	620
Flow Rate (gpm)	.07	.11	.15	.21	.27	.35	.43
Flow Rate (lpm)	.26	.41	.59	.80	1.04	1.32	1.63

DATA SHEET
