ATLAS COPCO U110 Utility Series 8 Air Compressor
- Found a better deal? Message us to price match.
Same-day dispatch
In-stock orders by 2pm AEST
Australia-wide delivery
Direct to your job from Brisbane
Authorised service
In-house warranty + repairs
Trade pricing for all
No trade-only accounts
The Atlas Copco U110 is a compact 8 Series Utility air compressor that delivers 100 CFM of free air at 100 psi (7 bar) normal effective working pressure.
The Utility range has no wheels but is still easy to move, thanks to integrated lifting slots and a top-hook. Every 8 Series compressor weighs under 750kg and can be serviced in under an hour, and each unit is finished with a corrosion free C3 rated canopy.
Features
Fuel Efficiency: Engineered for low fuel consumption.
Compact Footprint: A footprint at least 10% smaller than comparable models.
Anti Air Lock: Anti-air lock starting system.
Corrosion Protection: High humidity C3 corrosion protection.
Long Service: 1000 hour service interval.
Lifting Points: Integrated lifting slots and top-hook.
Full Shift Fuel: Enough fuel autonomy to run a full shift.
Included accessories
Specifications
| Working Pressure | 7 bar(g) (100 psi) |
|---|---|
| Free Air Delivery | 100 cfm |
| Max. Ambient Temperature At Sea Level | 50 degrees C |
| Min. Starting Temperature / Cold Start Kit | -10/-20 degrees C |
| Engine Make | Kubota |
| Engine Type | D902 |
| Number Of Cylinders | 3 |
| Output At Rated Speed | 18,5 kW |
| Engine Speed (nominal) | 3600 rpm |
| Engine Speed (unloaded) | 2000 rpm |
| Engine Oil Capacity | 3 L |
| Compressor Oil Capacity | 5 L |
| Fuel Tank | 30 L |
| Cooling System | 5 L |
| Dimensions (L x W x H) | 1580mm x 740mm x 850mm |
| Weight | 488 kgs |
