ATLAS COPCO U110 PACE Utility Series 8 Air Compressor
Features
Atlas Copco U110 PACE Utility Series 8 Air Compressor
Overview
The U110 PACE compressor is a new addition to the 8 Series Utility range. This compressor features an innovative controller allowing for multiple pressure configurations between 5-10.5 bar.
Thanks to its PACE (Pressure Adjust through Cognitive Electronics) system, operators are able to choose from the widest operating pressure range currently available for a truck-mounted air compressor. With the PACE electronic regulation system, operators use a simple-to-use digital controller to adjust the pressure with pinpoint accuracy depending on their application need. This means that with the U190 PACE compressor any theoretical combinations from 5 up to 10.5 bar is achievable.
The 8 Series Utility range is light weight, copact package. This range may not have any wheels, but all the integrated features mean we are proud to call this a mobile, easy to move compressor.
All 8 Series compressors are under 750 kg and service can always be completed under one hour. The Utility range offers models with our revolutionary PACE system. PACE enables you to control the pressure and regulate the flow – giving you even more versatility to handle the toughest applications. All models come with a corrosion free C3 rated canopy.
Specifications
Performance
Normal effective working pressure |
bar(g) |
5-10,5 |
Normal Effective working pressure |
psig |
70-150 |
Actual free air delivery |
cfm |
45-100 |
Max. ambient temperature at sea level | degrees celsius | 50 |
Min. starting temperature/ cold start kit | degrees celsius | -10/-20 |
Engine
Make |
Kubota |
Type |
D902 |
Number of cylinders |
3 |
Output at rated speed |
18,5 kW |
Engine Speed (nominal) | 3600 rpm |
Engine speed (unloaded) | 2000 rpm |
Capacity engine oil system | 3L |
Capacity compressor oil | 5L |
Fuel Tank | 30L |
Cooling system | 5L |
Dimensions
Length (including - fixed tow bar) | 1580mm |
Width | 740mm |
Height | 850mm |
Weight | 498kgs |
- Best in class fuel efficiency
- A footprint at least 10% smaller than comparable models
- Anti-air lock starting systems
- High humidity C3 corrosion protection
- 1000 hours service interval
- Integrated lifting slots and top-hook
- Enough fuel autonomy to run a full shift
Features
