Peerless Black 14000 Belt Drive Compressors
Peerless Black 14000 Belt Drive Compressors
Skip to product information
1 of 1

Important

Please note: air compressors i.e piston type, are not designed to run continuously they must cut in and out. Direct drive models should only have up to a 40-50% duty cycle. Belt Drive hobby models are up to 60-70% and full industrial belt drive models are up to 75-85%. If the compressor runs over these duty cycles it could cause failure. Important - first check voltage on each building site as low voltage will cause the motor to fail on all compressors. It must have be better than 230 volt at peak times. Extension leads will cause voltage drop, it's better to use extra air hose.

Performance of all our belt driven air compressors are to AS4637.

  • GO Data Sheet Peerless Black PB14000
  • GO Data Sheet Peerless Air Compressor Black Roll Cage PB14000R
  • Peerless Installation Checklist
  • Peerless Warranty Information and Registration Form
  • Peerless Maintenance Checklist
  • Peerless Black 14000 Belt Drive Range

Peerless Black PB14000

Code PB14000
Model PB14000
Pump Displacement (CFM) 11 CFM
Free Air Delivery (LPM) 220 LPM
Max PSI 145
Motor HP 2.5
Warranty Pump
1 Year
Warranty Motor 1 Year
Tank Capacity (L) 50L
Pump up time to 100PSI 1.20 - 1.25 Min
Dimensions (mm) Weight (kg)
880Lx410Wx760H
63kg
Cooling Method Air cooled
Pump Type Alloy Side by side
Cylinders 2
Pump Head Tension 16 FT LB
22.4NM
Oil Capacity 1L
Pump RPM 895
Outlet Thread 1/4" BSP
Electricity 240V / 10A
Amps draw 9.3

Peerless Black PB14000R

Code PB14000R
Model Roll Cage
Pump Displacement (CFM) 11 CFM
Free Air Delivery (LPM) 220 LPM
Max PSI 145
Motor HP 2.5
Warranty Pump
1 Year
Warranty Motor 1 Year
Tank Capacity (L) 9L
Pump up time to 100PSI -
Dimensions (mm) Weight (kg)
865Lx395Wx545H
60kg
Cooling Method Air cooled
Pump Type Alloy Side by side
Cylinders 2
Pump Head Tension 16 FT LB
22.4NM
Oil Capacity 1L
Pump RPM 895
Outlet Thread 1/4" BSP
Electricity 240V / 10A
Amps draw 9.3



Peerless Black 14000 Belt Drive Compressors

SKU: PB14000

Peerless Black 14000 Belt Drive Compressors

Regular price $1,165.00 AUD
Sale price $1,165.00 AUD Regular price
Save $0
Sold out
Inclusive of GST. Shipping calculated at checkout.
Style

Other payment options

The Basics

Compact performance: 220L/min free air. Alloy pump on a 50L tank, price point air compressor that has performance. Impressive performance in a compact design.

The Peerless Black 14000 is a great entry level belt drive air compressor, this runs super quiet and this is due to the pump only revving at a 895RPM! With all air compressors you should pay close attention to the pump RPM, if its RPM is over 1500-1800RPM you're over working your pump - would you drive your car in second gear at 100km/h?
It's the same when it comes to air compressors, overheating, atomising the oil and motor failures are just some of the failures that can occur.

This light industrial air compressor is designed for the building industry and home handyman, its unique design with caster wheels on the front and pneumatic wheels on the back makes it very easy to move from job to job.

For a light industrial air compressor it packs a lot of punch but it also has its limitations, keep in mind for high air demands you will have to step it up to a bigger air compressor like a belt drive, be sure to check your air tools for the air flow requirements but most importantly use our "Find the right air compressor" tool located on our home page to assist in making the right decision for your air needs.

Able to run;

  • Low pressure spray gun
  • Car tyre inflation gun
  • Stapling / fitting gun
  • Framing / grease gun
  • Chalking / riveter gun
  • Screw driver
  • 1/2" Ratchet / impact gun
  • Air duster

Important

Please note: air compressors i.e piston type, are not designed to run continuously they must cut in and out. Direct drive models should only have up to a 40-50% duty cycle. Belt Drive hobby models are up to 60-70% and full industrial belt drive models are up to 75-85%. If the compressor runs over these duty cycles it could cause failure. Important - first check voltage on each building site as low voltage will cause the motor to fail on all compressors. It must have be better than 230 volt at peak times. Extension leads will cause voltage drop, it's better to use extra air hose.

Performance of all our belt driven air compressors are to AS4637.

  • GO Data Sheet Peerless Black PB14000
  • GO Data Sheet Peerless Air Compressor Black Roll Cage PB14000R
  • Peerless Installation Checklist
  • Peerless Warranty Information and Registration Form
  • Peerless Maintenance Checklist
  • Peerless Black 14000 Belt Drive Range

Peerless Black PB14000

Code PB14000
Model PB14000
Pump Displacement (CFM) 11 CFM
Free Air Delivery (LPM) 220 LPM
Max PSI 145
Motor HP 2.5
Warranty Pump
1 Year
Warranty Motor 1 Year
Tank Capacity (L) 50L
Pump up time to 100PSI 1.20 - 1.25 Min
Dimensions (mm) Weight (kg)
880Lx410Wx760H
63kg
Cooling Method Air cooled
Pump Type Alloy Side by side
Cylinders 2
Pump Head Tension 16 FT LB
22.4NM
Oil Capacity 1L
Pump RPM 895
Outlet Thread 1/4" BSP
Electricity 240V / 10A
Amps draw 9.3

Peerless Black PB14000R

Code PB14000R
Model Roll Cage
Pump Displacement (CFM) 11 CFM
Free Air Delivery (LPM) 220 LPM
Max PSI 145
Motor HP 2.5
Warranty Pump
1 Year
Warranty Motor 1 Year
Tank Capacity (L) 9L
Pump up time to 100PSI -
Dimensions (mm) Weight (kg)
865Lx395Wx545H
60kg
Cooling Method Air cooled
Pump Type Alloy Side by side
Cylinders 2
Pump Head Tension 16 FT LB
22.4NM
Oil Capacity 1L
Pump RPM 895
Outlet Thread 1/4" BSP
Electricity 240V / 10A
Amps draw 9.3



View full details
