GO Solenoid Valve Coil 14.4mm 12v DC 20 W c/w DIN Plug SC-N14

SKU: SC-N14

$55

GO Solenoid Valve Coil 14.4mm 12v DC 20 W c/w DIN Plug SC-N14

Coil & Din Plug to suit ES55-2-4, B36/S36/WS36-7-40~9-50.20 Watts Insulation Class F DIN 43650-A IP65.47.2mm Long, 35.8mm Wide, 40.4mm High, 14.4mm whole centre.

  • Operator Size 14.4mm
  • Watts 20
  • Volt Amps 21
  • Voltage All
  • Insulation Class H
  • Rating IP65

      Solenoid Coil and DIN Plug to suit 12mm operator. It can suit any brand solenoid valve as long as it complies to the specs of this coil, our models are listed below.

      Valve Series Description
      B36 Brass 2/2 General Purpose Differential Normally Open (above 1”)
      S36 Stainless Steel 2/2 General Purpose Differential Normally Open (above 1”)
      WS36 Stainless Steel 2/2 Watermark Differential Normally Open (above 1”)
      A67 Aluminium 3/2 Differential Normally Open
      ES55D Stainless Steel 2/2 Direct Acting Normally Closed (1/4”)
